K782 - Steel POM Bushing
| Kastaş No | d(f7) | D(H7) | L | S3 |
|---|---|---|---|---|
| K782-014 | 14 | 16 | 20 | 0.98 |
| K782-028 | 28 | 32 | 30 | 1.95 |
| K782-028/1 | 28 | 32 | 50 | 1.95 |
| K782-030 | 30 | 34 | 25 | 1.95 |
| K782-030/1 | 30 | 34 | 30 | 1.95 |
| K782-030/2 | 30 | 34 | 50 | 1.95 |
| K782-030/3 | 30 | 34 | 60 | 1.95 |
| K782-032 | 32 | 36 | 20 | 1.95 |
| K782-035 | 35 | 39 | 20 | 1.95 |
| K782-035/1 | 35 | 39 | 30 | 1.95 |
| K782-035/2 | 35 | 39 | 35 | 1.95 |
| K782-040 | 40 | 44 | 40 | 1.95 |
| K782-040/1 | 40 | 44 | 50 | 1.95 |
| K782-040/2 | 40 | 45 | 20 | 1.95 |
| K782-040/3 | 40 | 45 | 30 | 1.95 |
| K782-045 | 45 | 50 | 40 | 2.43 |
| K782-045/1 | 45 | 50 | 50 | 2.43 |
| K782-050 | 50 | 55 | 30 | 2.43 |
| K782-050/1 | 50 | 55 | 40 | 2.43 |
| K782-050/2 | 50 | 55 | 45 | 2.43 |
| K782-050/3 | 50 | 55 | 50 | 2.43 |
| K782-050/4 | 50 | 55 | 60 | 2.43 |
| K782-060 | 60 | 65 | 40 | 2.43 |
| K782-060/1 | 60 | 65 | 50 | 2.43 |
| K782-060/2 | 60 | 65 | 60 | 2.43 |
| K782-070 | 70 | 75 | 40 | 2.43 |
| K782-070/1 | 70 | 75 | 50 | 2.43 |
| K782-070/2 | 70 | 75 | 58 | 2.43 |
| K782-070/3 | 70 | 75 | 60 | 2.43 |
| K782-070/4 | 70 | 75 | 90 | 2.43 |
| K782-075 | 75 | 80 | 40 | 2.43 |
| K782-075/1 | 75 | 80 | 60 | 2.43 |
| K782-075/2 | 75 | 80 | 80 | 2.43 |
| K782-075/3 | 75 | 80 | 90 | 2.43 |
| K782-080 | 80 | 85 | 40 | 2.41 |
| K782-080/1 | 80 | 85 | 50 | 2.41 |
| K782-080/2 | 80 | 85 | 60 | 2.41 |
| K782-085 | 85 | 90 | 60 | 2.41 |
| K782-090 | 90 | 95 | 50 | 2.41 |
| K782-090/1 | 90 | 95 | 60 | 2.41 |
| K782-090/2 | 90 | 95 | 90 | 2.41 |
| K782-095 | 95 | 100 | 45 | 2.41 |
| K782-095/1 | 95 | 100 | 60 | 2.41 |
| K782-100 | 100 | 105 | 50 | 2.41 |
| K782-100/1 | 100 | 105 | 60 | 2.41 |
| K782-100/2 | 100 | 105 | 90 | 2.41 |
| K782-110 | 110 | 115 | 60 | 2.41 |
| K782-110/1 | 110 | 115 | 80 | 2.41 |
| K782-120 | 120 | 125 | 100 | 2.41 |
| K782-120/1 | 120 | 125 | 60 | 2.41 |
| K782-130 | 130 | 135 | 100 | 2.41 |
.jpg) | ||||
| Kastaş K782 bushings use high quality steel as base, sintered porous bronze as its interlayer and the fibered POM as its surface. Kastaş K782 offers the property of low friction coefficient, silent operating and low wear. PRODUCT ADVANTAGES • Wear resistance • Low friction forces and long service life • High load resistance | ||||
| MATERIAL STRUCTURE | ||||
|
| TECHNICAL DATA | |||||||||||||||||||||||||
| |||||||||||||||||||||||||
